MODEL 700 CONTROL VALVE
Table 1-2: Part description for Model 700 Control Valve NPS 16 (continued)
Item number Description Quantity
6 Backup ring 2
7 O-ring 2
11 Spring 2
12 O-ring 1
13 Cylinder head 1
14 O-ring 8
16 Screw 24
17 Jack-out screws 2
18 Indicator stem micro-switch 1
31 Nuts 8
32 Valve body 1
33 Studs 40
34 Pipe plug 2
38 Cap plug 1
39 O-ring 8
43 Upper bearing 1
44 Indicator guard 1
45 Screw 2
46 Washer 2
47 Indicator adapter 1
55 Indicator Ext. guard 1
56 Screw 4
57 Washer 4
58 Piston plug 1
59 Screw 3
1.7 Agency certifications for control valves Model
700
The following product agency certifications are applicable to the Daniel control valves.
Table 1-3: Agency certifications for control valves
Certification type Description
Pressure equipment PED
