MODEL 700 CONTROL VALVE
Table 2-1: Operating conditions for the control valve (continued)
Condition type Description
Maximum safe working
pressure
Flange connections/Ratings (DIN) for valve sizes DN50 and DN400:
• DIN PN16 MWP at 120° C: 16 bar
• DIN PN25 MWP at 120° C: 25 bar
• DIN PN40 MWP at 120° C: 40 bar
• DIN PN64 (class 300) MWP at 120° C: 51 bar
• DIN PN64 (class 600) MWP at 120° C: 64 bar
• DIN PN100 MWP at 120° C: 100 bar
Flange connections/Ratings (ANSI) for valve sizes 2-in to 16-in:
• Class 150 MWP at 100° F: 285 psi
• Class 300 MWP at 100° F: 740 psi
• Class 600 MWP at 100° F: 1480 psi
* MWP: Maximum Working Pressure
Materials of construction Main valve body: Steel, ASTM-A352 Gr. LCC
Main valve cylinder:
• NPS 2-4: Stainless steel
• NPS 6 and larger: Nickel coated steel
Main valve piston: Stainless steel (standard)
Seat ring:
• Class 150 and 300:
— NPS 2-6: Stainless steel
— NPS 8-16: Nickel coated steel
• Class 600: Stainless steel
O-Rings:
• Standard: FKM
• Optional: CR, EPR, FKM V1289, NBR, FFKM, FKM GLT
• For other material contact the factory
External hook up:
• Class 150 and 300:
— NPS 2-6: Carbon steel/Stainless steel 10 mm (0.375-in)
— NPS 8-16 Carbon steel/Stainless steel 13 mm (0.5-in)
• Class 600:
— NPS 2-6: Stainless steel 13 mm (0.5-in)
— Can be furnished in metric sizes
Other internal parts: Stainless steel
Operating conditions and specifications User manual
