values, sequencing patterns and application rates provided here to achieve an adequate
seal.
Tighten each fastener at the following application rate:
• Install Nut - apply less than 20% of the suggested torque
• Second Pass - apply 20% - 30% of the suggested torque
• Third Pass - apply 30% - 70% of the suggested torque
• Fourth Pass - apply 100% of the suggested torque
• Fifth Pass - apply 100% of the suggested torque four (4) hours after Fourth Pass
Table 9-1: Valve cylinder head to body (stud-nut) suggested starting torque values by
stud material
(1)(2)
B7M / L7M
Stud size (in)
Suggested starting torque
range lbf·ft (N·m)
B7 / L7
Stud size (in)
Suggested starting torque
range lbf·ft (N·m)
Lower limit Upper limit Lower limit Upper limit
3/8 - 16 21 (28) 24 (32) 3/8 - 16 28 (38) 31 (42)
7/16 - 14 27 (36) 30 (41) 7/16 - 14 35 (48) 39 (54)
1/2 - 13 41 (55) 45 (61) 1/2 - 13 53 (72) 59 (80)
5/8 - 11 79 (107) 88 (119) 5/8 - 11 103 (140) 115 (156)
3/4 - 10 137 (186) 153 (207) 3/4 - 10 180 (244) 200 (271)
7/8 - 9 218 (296) 243 (329) 7/8 - 9 287 (388) 319 (432)
1 - 8 325 (440) 361 (490) 1 - 8 426 (578) 474 (642)
1- 1/8 - 8 470 (638) 523 (708) 1-1/8 - 8 617 (837) 686 (930)
1-1/4 - 7 640 (867) 710 (963) 1-1/4 - 7 839 (1138) 932 (1264)
1- 3/8 - 8 878 (1191) 976 (1323) 1-3/8 - 8 1153 (1563) 1281 (1737)
(1) Values are FOR REFERENCE only. Daniel provides the torque values in this table to help users
establish a starting point to achieve an adequate unit assembly clamping force. Torque values
reflect threads and nut bearing surfaces being bare metal well-lubricated with thread compound
assembled in a controlled factory environment.
(2) The final torque required to achieve an adequate seal may be higher or lower than the range
provided in this Table
