Socket and Gland Identification
KMP-V
A: 230Vac from mains
B: 24Vac to MULTICAL
C: LS-X Liquid Sensor, Alarm Relay
D: Alarm Relay, PIR sensor
E: Data Link to MULTICAL
G: Cut-off Valve
A
B
C
D
G
E
