DanTaet a/s
User Manual System KMP-V
110101 func. spec. 160926
Doc.No. 417106
Revision 170823
Page 24 of 26
Jumper Settings
Jumper row A-D: Monitoring Parameters
Position A: Max Dischg(H) B: Cutoff (L)
Classic PSALM
C: Idle Per. D: Tolerance
1 10 l 10 l/h 0% 10 s 1 imp
2 20 l 20 l/h 2/4% 20 s 2 imp
3 50 l 50 l/h 4/8% 50 s 5 imp
4 100 l 100 l/h 6/12% 100 s 10 imp
5 200 l 200 l/h 8/16% 200 s 20 imp
6 500 l 500 l/h 10/20% 500 s 50 imp
7 1000 l 1000 l/h 12/24% 1000 s 100 imp
8 2000 l 2000 l/h 14/28% 2000 s 200 imp
A: Max Dischg:
(H): No jumper: System uses a default value (200 l), adjustable by PC (hpdis) and
automatically after aminimum 7 day run-in. Otherwise jumper * scale factor.
(L): Irrespective of jumper settings, a default value (20 l) is used, adjustable by PC (lpdis)
and automatically after a minimum 7 day run-in.
B: Cutoff (Classic):
(H): Irrespective of jumper settings, a default value (20 l/h) is used, adjustable by PC
(hpcof) and automatically after a minimum 7 day run-in.
(L): No jumper in row B: Discharge monitor disabled in both phases. Otherwise the
jumper setting is used in Phase L.
PSALM: the chosen cutoff setting is used in both phases.
No jumper in row C: System uses a default value (1000 sek), adjustable by PC to the
values indicated, and automatically after a minimum 7 day dun-in.
No jumper in row D: seepage monitor disabled.
Jumper row E: Relay Configuration
Pos 1 On/Off = Max.Alarm to J17
Pos 2 On/Off = Seepage Alarm to J17
Pos 3 On/Off = LS-X alarm to J17
Pos 4 On/Off = System errors to J17
Pos 5 On/Off = Pump Stop (valve closed) to J16
Pos 6 On/Off = Holiday to J16
Pos 7 On/Off = Duplicate J17 selected leakage alarms on J16
Pos 8 On/Off = System errors to J16
Jumper row F: Options
Pos 1-3: Function Selection for digital inputs, se table next page.
Pos 4 On/Off = Liquid Sensor installed/not installed
Pos 5 On/Off = Wet liquid sensor closes/does not close valve
Pos 6 On/Off = IRPT 100 l/imp
Pos 7 On/Off = IRPT 10 l/imp
Pos 8 On/Off = IRPT 1 l/imp
