Dantherm DFC 350 - Wiring Diagram - FAC 48

21
840121 • Version 1.3 • 09.01.2012
Wiring diagram – FAC 48
CONTROLLER
FAC 48
D1 D2 D3 D4 D5 D6
S1
C
FR
C
FL
C
LD
C
TR
C
+P
-P
E+ E-
C+ C-
A1 A1 A2 A2 A3 A3 A4 A4 Y2
C
Y1
C OT C
RT
C
T1 T2 T3 T4
C
EXHAUST DAMPER MOTOR
(LM 24 KTE)
FIRE DETECTION
ALARM IF BROKEN
FILTER MONITOR ALARM
BUTTON FOR TIMER
230V AC LINE DETECTION
ALARM IF BROKEN
ROOM TEMPERATURE
SENSOR (RG-TD5A)
OPTION OUTDOOR TEMPERATURE
SENSOR (UG-TD5A)
FILTER ALARM
(NC/NO ADJUSTABLE)
FAN ALARM
(NC/NO ADJUSTABLE)
LOW TEMP ALARM
(NC/NO ADJUSTABLE)
HIGH TEMP ALARM
(NC/NO ADJUSTABLE)
PE N L
HEATER
AC START CIRCUIT
12V DC 12V DC
DATA COMMUNICATION
RC-232
5
Brown
Red 2
White 3
Green
CONNECTOR
MALE
Black 1
FEMALE
CONNECTOR
White
Green
Brown
White
7
2
2x0.25
FILE: FAC 48 DFC 101112
1
2
3
4
5 6
Brown Blue
+ Brown
- Blue
Battery Supply 48 VDC
10 A Fuse
Battery Supply Unit
2 x 1,5
3
+48V
0-10V
An
GND
FAN 48 VDC
2
Blue
White
Yellow
4
3
JUNCTION BOX
Red
1
FILTER MONITOR
Brown
White
2
3
6
5
Free Cooling Unit
OPTION
OPTION
