10
Fittings and installations, continued
Step
Action
7
Mount the front
door again
8
Make a water trap which meets the measurements on the picture and pour wa-
ter in it. Alternatively you can use the water trap from Dantherm (accessories):
9
Connect the hose to the drain The drain pipe must be kept frost proof all the
way, to ensure that the water can run unhindered.
The drain pipe must at least fall by 1 % all the way from the unit to the drain
outlet.
10
Dantherm A/S recommends insulated flex ducts when connecting to connect-
ors/coupling connectors. The ducts must be completely stretched to avoid un-
necessary loss of pressure.
Make sure you connect the ducts to the right connectors: The ducts must not
”hang” from the unit without support.
Dantherm recommends that the ducts are mounted with a flexible hose con-
nection, to make the connection easier and to damp noise and vibrations from
the installation.
HCH 5
HCH 8
Continued overleaf
