19
Auger
Assemblies
Ref.
No.
Part Number by Auger Diameter
Description
No.
Req’d
4" 6" 9" 12" 14" 16" 18" 24"
1 See next page for available augers. Auger 1
2
7782 7783 Plain Cutting Edges (Weld On) 1 Set
7784 7790 7792 7794 7796 7798 Plain Cutting Edges (with Bolts & Nuts) 1 Set
3 7785 7791 7793 7795 7797 7799 Serrated Cutting Edges (with Bolts & Nuts) 1 Set
4 899 831 831 831 831 831 831 831 Standard Auger Point 1
5 6019 6019 6019 6019 6019 6019 6019 6019 Auger Adapter Replacement (for Field Welding) 1
6 784 784 784 784 784 784 Cutting Edge Bolt (3/8" 16 x 1" Carriage) As Req’d
7 785 785 785 785 785 785 Cutting Edge Nut (3/8" 16 Hex) As Req’d
8 6014 6014 6014 6014 6014 6014 6014 6014
Retaining Bolt (1/2" 13 x 3-1/4" Gr. 8, 1/2" of thread)
SPECIAL BOLT: Use Genuine Danuser Replacement Only
1
9 1056 1056 1056 1056 1056 1056 1056 1056 Retaining Nut (1/2" 13 Hex) 1
10
6080G 6080G 6080G 6080G 6080G 6080G 6080G 6080G Auger Extension with Guard (7") 1
6204G 6204G 6204G 6204G 6204G 6204G 6204G 6204G Auger Extension with Guard (14") 1
11 6239 6239 6239 6239 6239 6239 6239 6239
Coiled Pin (1/2" x 2-3/4")
SPECIAL PIN: Use Genuine Danuser Replacement Only
1
12 1937 1937 1937 1937 1937 1937 1937 Special Duty Auger Point 1
13 6210 6210 6210 6210 6210 6210 6210 Aggressive Duty Auger Point 1
Augers have replaceable points and edges. Serrated cutting edges (Ref. No. 3) and optional points (Ref. No. 12 and
Ref. No. 13) are available to aid penetration in tough digging conditions. Flights are replaceable except on 4" and 6",
where the flight is a continuous spiral. Cutting edges on 4" and 6" augers are welded on the auger.
NOTE
When using an extension, Ref. No. 8 (PN 6014) and Ref. No. 9
(PN 1056) should be relocated from the auger adapter to the
extension adapter, and Ref. No. 11 (PN 6239) should be used to
attach the auger to the extension to avoid possible entanglement.
DANGER
AUGER ASSEMBLIES FOR 2" ROUND SPINDLES
= Safety Sign Location
