DCP-24 MKII Digital Cross Over
Product code: D2083
Product Specifications
Model:
DCP-24 MKII Digital Cross Over
Electrical:
Power supply:
220–240 V AC, 50 Hz
Output voltage:
6 V DC
SMPS:
Yes
Power consumption:
4 W
Power connector:
Low-voltage DC plug
Data connector:
USB-B connector
Outputs:
Main outputs:
4 x 3-pin XLR balanced connector
Main output headroom:
9 dB
Main output maximum level:
0 dBu
Main output impedance:
100 Ω
Inputs:
Mono inputs:
2 x 3-pin balanced connector
Mono input headroom:
22 dB
Mono input gain range:
12 dB
Mono balanced input max. level:
22 dBu
Mono input impedance:
10000 Ω
Audio Specifications:
THD level:
< 0,01 %
Signal-to-noise ratio:
> 90 dB
Audio latency:
1,27 ms
DSP processor bitrate:
64 bit
Frequency response:
20–20000 Hz
Software Specifications:
Supported operating systems:
Windows/MacOS
Sound editing:
Equalizer range:
12 dB
Parametric input equalizer:
5 bands
Parametric output equalizer:
5 bands
Equalizer types (input):
Allpass/Bell/High Shelf/Low Shelf/Notch
Equalizer types (output):
High Shelf 6/High Shelf 12/Low Shelf 6/Low Shelf 12
Crossover filter types:
Bessel/Butterworth/Linkwitz Riley
Crossover slopes:
6/12/24/48 dB
Dynamics type:
Limiter
Phase reverse:
Yes
Limiter threshold:
From -20 to +20 dB
Limiter release time:
1–100 ms
Max. output delay:
8 ms
Internal storage:
User presets capacity:
50
Physical:
Dimensions:
483 x 155 x 44,5 mm (L x W x H), 19” x 1 U
Installation depth (excl. connectors):
155 mm
Weight:
1,9 kg
