DAPAudio DCP-24 MKII User Manual

24
DCP-24 MKII Digital Cross Over
Product code: D2083
● BUT 24 dB
● BES 24 dB
● LR 24 dB
04) Press the jog wheel (09) to activate/deactivate the filter. The display shows:
05) Turn the jog wheel (09) to the left/right to select OFF/ON.
PEQ (Parametric Equalizer)
In this menu you can set the parametric equalizer. Each channel has 5 parametric equalizers (PEQ 1–5).
01) Turn the jog wheel (09) to the left/right to decrease/increase the value. The adjustment range is
20– 20000 Hz.
02) Press the jog wheel (09) to open the gain settings. The display shows:
03) Turn the jog wheel (09) to the left/right to decrease/increase the value. The adjustment range is from
-12 dB to +12 dB.
04) Press the jog wheel (09) to open the quality factor settings. The display shows:
05) Turn the jog wheel (09) to the left/right to decrease/increase the value. The adjustment range is
0,10– 25.
06) Press the jog wheel (09) to open the type settings. The display shows:
07) Turn the jog wheel (09) to the left/right to select the filter type. Select one of the following 8 filters:
● BELL
● NOTCH
● HIGH SHELF
● LOW SHELF
● ALLPASS
● BAND PASS
● HIGH PASS
● LOW PASS
08) Press the jog wheel (09) to activate/deactivate the filter. The display shows:
09) Turn the jog wheel (09) to the left/right to select OFF/ON.
