DAPAudio DCP-24 MKII User Manual

42
DCP-24 MKII Digital Cross Over
Product code: D2083
You can set the high-pass filter (HPF) and the low-pass filter
(LPF).
Type the value manually in the field. The adjustment range is
0–20000 Hz.
Select the filter type (BUT - Butterworth, BES - Bessel or LR -
Linkwitz Riley):
● BUT 6 dB
● BES 6 dB
● BUT 12 dB
● BES 12 dB
● LR 12 dB
● BUT 18 dB
● BES 18 dB
● BUT 24 dB
● BES 24 dB
● LR 24 dB
8. Troubleshooting
This troubleshooting guide contains solutions to problems which can be carried out by an ordinary
person. The device does not contain user-serviceable parts. Unauthorized modifications to the device will
render the warranty void. Such modifications may result in injuries and material damage. Refer servicing
to instructed or skilled persons. Contact your Highlite International dealer in case the solution is not
described in the table.
Problem
Probable cause(s)
Solution
The device does not
function at all
No power to the device
● Check if power is switched on and
cables are plugged in
Internal fuse is blown
● Return the device to your DAP dealer
No sound
The volume is set to minimum
● Increase the volume
Incorrect settings
● Correct the settings of the device
● Correct the settings of the DSPControl
software
Incompatible devices
● Make sure that the connected devices
are compatible
Incorrect polarity of the
connections
● Examine if the polarity of the
connections between the devices is
correct
