19
LOCATION 198: BELL TEST CONTROL
Location 198 is used to assign the BELL TEST Control characteristics for the DL250. There are four options in this location,
each of which will cause a siren output on a different system condition. You are able to program one of these options or any
combination of. If Set for (1) + (7) Bell test (Value = 1) is enabled, then the simultaneous pressing of keys [1] + [7] on the
code pad will case an audible alarm activation for the period of the siren time. This feature should be used to test your
system sirens and/or strobes, an entry of a valid code will switch off this feature. A 500 ms siren output will be generated
when the following feature are enabled; Activate on arming (Value = 2) (whenever a valid code is entered to arm the DL250
or a partition of), Activate on exit delay- expiration (Value = 4) (activates at the end of the primary exit delay), Activate at
closing kissoff (Value = 8) (activates upon a communication of a closing report).
VALUE BELL TEST CONTROL VALUE BELL TEST CONTROL
0 NO FEATURE ENABLED 8 ACTIVATE AT CLOSING KISSOFF
1 SET FOR [1] & [7] BELL TEST 9 SET FOR [1] & [7] BELL TEST
ACTIVATE AT CLOSING KISSOFF
2 ACTIVATE ON ARMING 10 ACTIVATE ON ARMING
ACTIVATE AT CLOSING KISSOFF
3 SET FOR [1] & [7] BELL TEST
ACTIVATE ON ARMING
11 SET FOR [1] & [7] BELL TEST
ACTIVATE ON ARMING
ACTIVATE AT CLOSING KISSOFF
4 ACTIVATE ON EXIT DELAY-
EXPIRATION
12 ACTIVATE ON EXIT DELAY EXPIRATION
ACTIVATE AT CLOSING KISSOFF
5 SET FOR [1] & [7] BELL TEST
ACTIVATE ON EXIT DELAY-
EXPIRATION
13 SET FOR [1] & [7] BELL TEST
ACTIVATE ON EXIT DELAY EXPIRATION
ACTIVATE AT CLOSING KISSOFF
6 ACTIVATE ON ARMING
ACTIVATE ON EXIT DELAY-
EXPIRATION
14 ACTIVATE ON ARMING
ACTIVATE ON EXIT DELAY EXPIRATION
ACTIVATE AT CLOSING KISSOFF
7 SET FOR [1] & [7] BELL TEST
ACTIVATE ON ARMING
ACTIVATE ON EXIT DELAY-
EXPIRATION
15 SET FOR [1] & [7] BELL TEST
ACTIVATE ON ARMING
ACTIVATE ON EXIT DELAY EXPIRATION
ACTIVATE AT CLOSING KISSOFF
LOCATION 199: RESERVED
LOCATION 200: ISOLATED ZONE BEEP ENABLE
If a "1" is programmed in location 200, the Code Pad sounder will create a pulsed output if a valid code is utilised to arm
the DL250 when one or more zones are isolated. The code pad sounder can be silenced by re-entering a valid used code
or waiting until the end of the primary exit time. If a "0" is programmed in this location, the control can be armed with one
or more zones isolated with no Code Pad sounder output. Factory default is "1" and Code Pad sounder will sound when
arming occurs with a zone isolated.
LOCATION 201: AC OFF BEEP ENABLED
If a "1" is programmed in location 201 the Code Pad buzzer will create a pulsed output if a valid code is used to arm or
disarm the DL250 with the AC power removed. The code pad sounder can be silenced by re-entering a valid used code
or waiting until the end of the primary exit time. If a "0" is programmed in this location, the control can be armed with the
AC power removed with no Code Pad sounder output. Factory default is "1" and the Code Pad sounder will sound if the
control is armed with no AC power.
LOCATION 202: PARTIAL ARM SECURITY FEATURE
If a "1" is programmed in location 202, a valid user code must be entered to disarm the control from the Partial Arm mode.
Factory default is "0", Partial Arm mode can be disarmed with the one digit code programmed in location 215.
LOCATION 203: FIRST TO OPEN LAST TO CLOSE ENABLE
If a "1" is programmed in location 203 a closing report will only be reported when all partitions have closed and an opening
report will be reported only when the first partition has been opened . The opening and closing communicator codes must
have enabled in the appropriate locations if opening/closing reports are to be reported. Note: If a common area is enabled
in location 246 the common area will always be the last area to arm. Therefore the closing report will be generated with user
28 and the primary account code to indicate a common area closing. Factory default is "0" and partitions will report opening
and closing individually.
