30
These locations should remain at factory default when Contact I.D and Ademco High Speed are selected.
LOCATION 336: TROUBLE CODE FOR Zones 1-8
Location 336 is used to program reporting of the Trouble code for zones (1 thru 16), when Contact I.D and Ademco High
Speed is selected. The Trouble communicator code can be reported when a Fire zone is in Trouble alarm (Refer to zone
types). When contact I.D is selected, program a one (1) in this location to enable this report, an event "380 - Zone Trouble"
will be reported. When using Ademco High Speed, program a one (1) in this location to enable this report. A one (1) will
be displayed for the channel corresponding to the zone that is in Trouble. EG, "5155 5555 5" will be reported for zone two
(2). Default for Trouble code is “1" enabled.
LOCATION 337: TROUBLE CODE FOR Zones 9-16
These locations should remain at factory default when Contact I.D and Ademco High Speed are selected.
LOCATION 338: ZONE TAMPER CODE FOR Zones 1-8
Location 338 is used to program reporting of the Zone Tamper code for zones (1 thru 16), when Contact I.D and Ademco
High Speed is selected. The Zone Tamper communicator code can be reported when a Double End Of Line Zone is in an
Open/Closed circuit condition (Refer to “zone reporting / special characteristics“). When contact I.D is selected, program
a one (1) in this location to enable this report, an event "137 - General Tamper" or program a two (2) in this location to
enable this report, an event "144 - Sensor Tamper". When using Ademco High Speed, program a one (1) in this location
to enable this report. A one (1) will be displayed for the channel corresponding to the zone that is in Tamper. EG, "5155
5555 5" will be reported for zone two (2). Default for Trouble code is “1" enabled.
LOCATION 339: TAMPER CODE FOR Zones 9-16
These locations should remain at factory default when Contact I.D and Ademco High Speed are selected.
LOCATION 340: OPENING COMMUNICATOR CODE
The DL250 has the ability to report an opening code each time the control is disarmed. The desired opening code is
programmed in location 340. To enable this communicator code report when Contact I.D or Ademco High Speed is
selected, program a one (1) in this location. Default for Opening code is “0" disabled.
LOCATION 341: CLOSING COMMUNICATOR CODE
The DL250 has the ability to report a closing code each time the control is armed. The desired closing code is programmed
in location 341. If this location contains a "0" closing will not be reported. When using Ademco high speed or contact I.D
formats a "1" is programmed into this location to enable closing reports. Default for Closing code is “0" disabled.
LOCATION 342: OPENING/CLOSING PHONE SELECTOR
If a phone number other than phone #1 is desired, I.E. for dual or split reporting. A binary number must be programmed into
this location. This is derived by adding a "1" for phone #1, a "2" for phone #2 and a "4" for the internal log. Factory default
is "5" which causes open/closing to report on phone #1 and internal log if the communicator event is enabled.
LOCATION 343: PROGRAMMING THE COMMUNICATOR CODE FOR CANCEL (EXCEPTION OPENING)
Location 343 contains the communicator code that will be sent for cancel. The cancel code programmed in this location
will be sent if an arm/disarm code is entered after an alarm on zones 1 through 16 has been reported (excluding 24 hour
zones). After a cancel has been reported, no zone restores will be transmitted on non-24 Hour zones. When contact I.D
is selected, program a one (1) in this location to enable this report, the event code “406" will be reported, followed by an
opening event with the user code number used. When using Ademco High Speed, program a one (1) in this location to
enable this report, the opening event will be reported with the user code number used. This feature can not be enable when
Open/Close reporting is also enabled. If this location contains a "0", cancel is disabled.
FOUR LOCATION COMMUNICATOR CODES
The following communicator codes are programmed in four locations. I.E. Data 1, 2, 3 and 4 (refer to page ?). When
Contact I.D. or Ademco High Speed is selected then programming a “1" in Data 1 for the selected location will enable the
