LOCATIONS 388-395: PROGRAMMING THE ZONE TYPES FOR ZONES 9-16
Locations 388 through 395 contain a number identifying the characteristics of zones 9 through 16. Location 388 corresponds
to zone 9 and location 395 corresponds to zone 16. These zones have been factory defaulted to instant (6) zone types.
Other zone characteristics can be found in the table on page 15.
LOCATIONS 396-403: ASSIGNING SPECIAL CHARACTERISTICS FOR ZONES 9-16
Locations 396-403 are used to assign zone characteristics for zones 9 through 16. Location 396 is for zone 9 and location
403 is for zone 16. Each zone can have any or all of the following characteristics regardless of the zone type selected in
locations 388-395 excluding Fire zones, which cannot be Isolated. Factory default is "12" for each of these locations,
meaning that Zone Isolate Capability & Partial Arm is enabled, and the other characteristics are not enabled. When Partial
Arm is enabled, that zone is active in Partial mode. Remove this option from the zone(s) which are to be isolated in Partial
mode. Note: zone will not isolate in partial mode or group isolate if (8) Zone Isolate Capability is not enabled. Other special
characteristics can be found in the table on page 16.
LOCATIONS 404-411: ASSIGNING AUDIBLE CHARACTERISTICS FOR Zones 9-16.
Locations 404-411 are used to assign the audible characteristics of zones 9 through 16. Location 404 is for zone 9 and
location 411 is for zone 16. Each zone can have one, or a combination of the following audible characteristics. To determine
the appropriate data for these locations, refer to the chart below and add the sum of the corresponding values to arrive at
the correct data for these locations. For all zones the factory default is "1". This means that zones 9-16 will create a yelp
siren output when an alarm is created. NOTE: If a Fire zone type is selected in locations 388-395, standard fire zone
characteristics will override any selection made for a zone in this section I.E. a steady siren will be generated for a short
circuit and a code pad sounder for an open circuit. Zones with a steady siren characteristic will over ride zones with a yelp
siren characteristic. If a chime zone is selected, then refer to locations 213 and 214 for more detail. Other audible
characteristics can be found in the table on page 16.
LOCATIONS 412-419: REPORTING / SPECIAL CHARACTERISTICS FOR Zones 9-16
Locations 412-419 are used to assign communicator characteristics to individual zones 9 through 16. Location 412 is for
zone 9, and location 419 is for zone 16. Each zone can have one, or a combination of these characteristics. Factory default
for all zones is (1 + 2 = "3"). This means that each zone has Restore Reporting (Value = 1), Isolate Reporting (Value
= 2) enabled. It should be noted that these locations are used to enable individual zone report capability by zone. A
reporting code must be programmed in the appropriate location to enable overall reporting capability of Restore reports
(location 332) Isolate reports (location 334). Twin trip zone 9 through 16 are also enabled in these locations. Program Twin
trip (Value = 8) to enable this feature. Double EOL Tamper is not available on zones 9 to 16.
VALUE REPORTING/SPECIAL CHARACTERISTICS VALUE REPORTING/SPECIAL CHARACTERISTICS
0 NO FEATURE SELECTED 7 RESTORE REPORTING u ISOLATE REPORTING u
DOUBLE EOL ENABLE
1 RESTORE REPORTING 8 TWIN TRIP ENABLE
2 ISOLATE REPORTING 9 RESTORE REPORTING u TWIN TRIP ENABLE
3 RESTORE REPORTING u ISOLATE REPORTING 10 ISOLATE REPORTING u TWIN TRIP ENABLE
4 NOT USED 11 RESTORE REPORTING u ISOLATE REPORTING u
TWIN TRIP ENABLE
LOCATION 420-423: PROGRAMMING THE COMMUNICATOR CODE FOR ZONE 9
Locations 420-423 are used to control the communicator code for zone 9. Zone 9 is automatically enabled and When
contact I.D is selected, the default report is an event "130 - Burglary" with point “09" when in alarm. Refer to appendix 1 if
a different event type is required. When using Ademco High Speed, Zone 9 is defaulted to report, a "1555 5555 7" when
in alarm. Ademco High Speed is a predefined format and only the Channel number can be programmed in Data 3. The
defaults are “3:0:9:5" with telephone number 1 and the event log enabled.
