#2
Locations 102-117 contain phone #2. This number allows certain communicator reports to go to another number (split reporting), or
to cause the communicator to dial a second number if the primary number does not respond after the number of attempts
programmed into location 133 have been tried unsuccessfully, or for dual reporting. The same number of attempts are made with
the back-up number. Tone dialing and delay instructions are the same as for the primary number. A "14" indicates the end of the
phone number.
Location 118-122: Programming The Account Code For Phone #2 (Or Partition Two)
Locations 118-122 contain the account code for phone #2. If the account code is three digits long, use locations 118, 119, and 120.
If a zero "0" is part of the account code it must be programmed as a "10". Program a "0" to indicate the end of the account code. If
these locations contain a "0", the account code in locations 96-100 will be reported. To make this account code the account code for
"Partition Two", see location 132.
Location 123: Communicator Format For Phone #2
Location 123 contains the communicator format used to transmit to the receiver connected to phone #2. Consult the instructions for
your central station receiver to determine which format is compatible. Select a format from the chart below. If you require a format
other than those listed, review the override options described in locations 610-615 to build the appropriate format. A "15" must be
programmed in location 123 in addition to the entries into locations 610-615 in order to create a special format. If this location
contains a "0", the format programmed into location 101 will be selected.
DATA FORMAT DESCRIPTION
0 LOCAL ONLY COMMUNICATOR IS DISABLED
1 ADEMCO CONTACT ID DTMF FORMAT
2 ADEMCO 4/2 EXPRESS DTMF FORMAT
3 PAGER FORMAT REPORTS IN 4 + 3 FORMAT AND/OR DOMESTIC DIALLING
4 ADEMCO HIGH SPEED DTMF FORMAT
5 RADIONICS EXTENDED SLOW 1800Hz TRANSMITTAL 230OHz HANDSHAKE 20 PPS HEX EXT DOUBLE
ROUND
6 CADDX MODEM PROPRIETARY
7 RADIONICS EXTENDED FAST 1800Hz TRANSMITTAL 230OHz HANDSHAKE 40 PPS HEX EXT DOUBLE
ROUND
8 RADIONICS EXTENDED FAST 1800Hz TRANSMITTAL 1400Hz HANDSHAKE 40 PPS HEX EXT DOUBLE
ROUND
9 RADIONICS EXT FAST W/PARITY 1800Hz TRANSMITTAL 230OHz HANDSHAKE 40 PPS HEX EXTENDED
10 NOT USED
11 ADEMCO/SILENT KNIGHT SLOW 190OHz TRANSMITTAL 140OHz HANDSHAKE 10 PPS DOUBLE ROUND
PARITY
12 SILENT KNIGHT 4+2 FAST 190OHz TRANSMITTAL 1400Hz HANDSHAKE 20 PPS DOUBLE ROUND
PARITY
13 SESCOA/FRANKLIN FAST 1800Hz TRANSMITTAL 230OHz HANDSHAKE 20 PPS HEX DOUBLE
ROUND
14
SIA
FSK FORMAT
15 CUSTOM FORMAT SELECT YOUR OWN FORMAT FOR NON STANDARD BASE STATIONS.
I REFER TO APPENDIX (3).
