DAS DL-300E - Zone Characteristics and Audibility; Special Characteristics (1-16); Audible Characteristics (1-16)

15
Location 155-170: Assigning Special Characteristics For Zones 1-16
Locations 155 through 170 are used to assign zone characteristics for zones 1 through 16. Location 155 is for zone 1 and location 170 is
for zone 16. Each zone can have any or all of the following characteristics regardless of the zone type selected in locations 139
-154
excluding Fire zones, which cannot have Isolate capability
enabled. Factory default is "12 for each of these locations, meaning that
Zone Isolate Capability & Partial Mode is enabled, and the other characteristics are not enabled. To include other characteristics, add their
value, and program the sum in the appropriate location. See the table below for zone characteristics and their corresponding values.
PARTIAL MODE NOTES
* Zones containing a “4” will be monitored in the
Partial Mode.
* Zones not containing a “4” will be automatically
isolated in the Partial Mode.
VALUE CHARACTERISTIC
1 Fast Loop Response
2 Group Isolate Zone
4 Partial Mode Zone
8 Zone Isolate Capability
Example 1
- To add Group Isolate Zone (Value=2) to Zone Isolate Capability (Value=8) for zone 10 (location 164),
add the value of the two characteristics (2 + 8 = 10'), and program the sum of '10' in location 164.
Example 2- To enable ALL characteristics for zone 10, add the value of all characteristics (1 + 2 + 4 + 8 ='15'),
and program the sum of '15' in location 164 (zone 10 characteristics location).
Example 3- To disable all characteristics and create a Non Isolatable Zone, program a'0' in the appropriate location.
Location 171-186: Assigning Audible Characteristics For Zones 1-16.
Locations 171-186 are used to assign the audible characteristics of each zone 1 through 16. Location 171 is for zone 1 and
location 186 is for zone 16. Each zone can be Silent (Value = ll), or have one, or a combination of the following audible
characteristics. To determine the appropriate data for these locations, refer to the chart below and add the sum of the
corresponding values to arrive at the correct data for these locations. For all zones except zone 2, factory default is "1". This
means that all 16 zones will create a yelp siren output when an alarm is created. To select the audible characteristics for any
zone, add the values of the audible characteristics from the table below, and program the sum in the appropriate locations
171186. If you wish for the zone to be Silent, program a "0" in the appropriate location. NOTE: If a Fire zone type is selected in
locations 139-154, standard fire zone characteristics will override any selection made for a zone in this section.
VALUE AUDIBLE CHARACTERISTICS
1 Yelp Siren Audible
2 Steady Siren Audible
4 Code pad Sounder Audible
8 Chime Feature
0 Silent Zone
