Standard Parts List
DL-300E
INSTALLATION
MANUAL
General
Description
The DAS DL-300E is a versatile 16 expandable to 32 zone up/downloadable security control with a built-in digital communicator. Its
microcomputer design gives some of the most versatile, yet easy to use features available for most security applications today.
Some of the features of the DL-300E include; Paritionable up to four separate systems, dual reporting, Partial Mode (for at home
monitoring), 30 user codes, internal log, time restriction options for user codes, dynamic battery test, domestic dialing format, plus
many more. Each of the 32 zones can be programmed to be one of nine different types including 24 Hour, Handover, Day Zone,
and secondary entry. The system can be used with LCD or LED code pads, keyswitches, or radio remote arming. Each zone is
individually annunciated and can be isolated from the code pad if so enabled. See page 14 for a description of all zone types. Read
the OPERATOR'S MANUAL before you begin the installation for the best overall description of how the DL-300E functions. After
installation of the security system, complete the information on page 1 of the operator's manual and explain the system operation to
all security system owners/operators.
QUANTITY PARTS DESCRIPTION PART #
1 MASTER CONTROL PANEL W/O CODE PAD FS4533
20 3K3 ½ WATT EOL RESISTORS EOL-33
1 (4) WIRE LEAD FOR AUX OUTPUTS 8920
1 INSTALLATION MANUAL IM-DL-300E
1 OPERATORS MANUAL OM-DL-300E
OPTIONAL PARTS DESCRIPTION PART #
16 LED REMOTE CODE PAD FS4531
LCD ALPHA NUMERIC DISPLAY CODE PAD FS4534
AC POWER SUPPLY 16.5V 3 AMP PLUG PACK FS4426
SMART PROGRAMMER WITH LCD DISPLAY FS461 0
PROGRAMMER WITH DIGITAL NUMERIC DISPLAY FS4597
8 WAY RELAY OUTPUT MODULE FS4634
16 WAY VOLTAGE OUTPUT MODULE FS4614
16 WAY X-10 VOLTAGE OUTPUT MODULE FS4804
12 VOLT 6.5 AMP HOUR BATTERY FS4312
