DAS DL-300E - Auxiliary Output Event Mapping; Event to Category;Event Code Mapping; Example Event Selection

20
DESCRIPTION OF EVENT DATA 3
CATEGORY
DATA 4
EVENT
"OPEN" on individual zone 1 thru 16 "0' "0-15'
"OPEN" on individual zones 17 thru 32 "1' "0-15'
"SHORT"on individual zones 1 thru 16 "2' "0-15'
"SHORT" on individual zones 17 thru 32 "3' "0-15"
"OPEN or SHORT"on individual zones 1 thru 16 "4' "0-15"
"OPEN or SHORT"on individual zones 17 thru 32 "5' "0-15'
"ISOLATE" of individual zones 1 thru 16 "6' "0-15"
"ISOLATE" of individual zones 17 thru 32 7' "0-15"
"TROUBLE" of individual zones 1 thru 16 "8. 'D-15'
"TROUBLE" of individual zones 17 thru 32 "9' "0-15'
"ALARM" of individual zones 1 thru 16 "10' "0-15"
"ALARM" of individual zones 17 thru 32 "11' "0-15'
Any "FIRE ALARM" "12' "0'
Any "PANIC ALARM" "1'
Any "BURGLARY ALARM" "2`
Any'TROUBLE CONDITION" "3'
Any "ISOLATE REPORT" "4'
Any "EARLY TO OPEN" "5'
Any "LATE TO CLOSE" "6'
"AC FAILURE REPORT" "7'
"DURESS" "8'
"AUXILIARY 1- [1] & [3] Double Keypress "9'
"AUXILIARY 2' [4 & [6] Double Keypress "10'
"Code pad PANIC" [*] & [#] Double Keypress "11'
"Code pad TAMPER" "12-
"AUTO TEST" '13'
"CHECK SUM" "14'
"CANCEL" "15'
Activation of "PRIORITY (FIRE) SIREN" "13" .0'
Activation of "BURGLARY SIREN" "1'
"ANY SIREN" "2°
Example 2 -
To select "Code pad PANIC" [*] & [#], your CATEGORY selection (Data 3) will be "12", and your EVENT
selection (Data 4) will be "11 ".
