30
7.0 CONTROLS
7.1 Standard Thermostat
A single stage cooling thermostat is standard on all Mini Ceiling units. Units with either humidifi ers
and/or electric reheat require the Mini DAP-II, the Mini DAP-III or the Remote Mount DAP-III.
7.2 Optional Programmable Thermostat
Optional single stage cooling thermostat allows simple programmable functions. Units with either
humidifi ers and/or electric reheat require the Mini DAP-II, the Mini DAP-III or the Remote Mount
DAP-III.
7.3 Optional Mini DAP-II Microprocessor Control Panel
The Mini DAP-II microprocessor control panel is available on all Mini Ceiling units. There is a sepa-
rate manual with extensive detail regarding the functions, features, programming and troubleshoot-
ing.
WARNING: The Mini DAP-II microprocessor control panel has an entire manual dedi-
cated to its use and operation. The manual must be referenced to complete a thorough
unit installation. Start-up is not complete until the Mini DAP-II control panel settings are
established.
7.4 Optional Mini DAP-III
The Mini DAP-III is available as an option and offers additional features including remote commu-
nications (with additional communication card options). There is a separate manual with extensive
detail regarding the functions, features, programming and troubleshooting.
WARNING: The Mini DAP-III microprocessor control panel has an entire manual dedi-
cated to its use and operation. The manual must be referenced to complete a thorough
unit installation. Start-up is not complete until the Mini DAP-II control panel settings are
established.
7.5 Optional DAP-III
The Remote Mount DAP-III is available as an option and offers additional features including remote
communications (with additional communication card options) and analog inputs/outputs. There
is a separate manual with extensive detail regarding the functions, features, programming and
troubleshooting.
