Total Flow: This is the total air flow of all units currently running in the zone.
Max Flow: This is the calculated maximum air flow that is capable for the zone.
Zone AF Demand: This is the calculated value based on how much of the total
airflow makes up the max flow.
C
O
2
S
e
t
po
i
n
t
s
S
e
t
P
o
i
n
t:
1000pp
m
D
ea
db
a
nd
:
25pp
m
M
i
n
V
a
l
v
e
O
n
:
5
s
V
a
l
v
e
P
W
M
:
10
%
Note: This screen is only shown on the gPOD model.
Setpoint: This is the amount of CO2 in parts per million that the controller will
maintain when CO2 regulation is required. Range of adjustment is 100 to 2000ppm
with a default value of 1000ppm.
Deadband: This is the amount CO2 may drop below the CO2 setpoint before the
CO2 valve is modulated. Range of adjustment is 25 to 1000ppm with a default
value of 25ppm.
Min Valve On: This is the minimum time that the C02 valve will be turned on when
there is demand. Range of adjustment is 0 to 32,767 seconds with a default value
of 5 seconds.
Valve PWM: This setting meters how fast CO2 is injected into the air by modulating
the on/off frequency in a 10 second period. For example, if set to 40%, the valve will
be on 4 seconds and off for 6 seconds. Range of adjustment is 10 to 100% with a
default value of 10%.
To Next Page
