AIR-COOLED FLUID COOLER
36 • Air-Cooled Condenser Manual
What is a time delay fuse?
Time delay fuses are used in general on
circuits with induction load that have initial
surges of electrical power when the motor
starts. Induction loads may be motor,
pump, etc.
What is a fast-acting fuse?
Fast acting delay fuses are used in general
on circuits with resistance load that have
initial surges of electrical power when the
resistance load starts. Resistance loads
may be electric heat, humidifier, etc.
Where is the unit wiring diagram?
Each unit is shipped with wiring diagram
inside the electrical control enclosure.
Contact Service Department for
replacement wiring diagram, if necessary.
What is the electrical rating for the unit?
The electrical ratings are located on the
unit serial name plate label.
What is the SCCR rating for the unit?
Short Circuit Current Rating (SCCR).
Unless specified, the SCCR rating is 10 kA
root mean square symmetrical, 600 volts
maximum.
