DataCard SP55 Plus User Manual

Page 1
About the printer
The outside of the printer
Duplex Module: Optional module at the back of
the printer.
Printer Cover.
Latch: Lift the latch to open the printer cover.
Input Hopper: Open the cover to load blank cards.
Output Hopper: Remove completed cards.
Ready button: Push to pause or resume
the printer.
The status light helps you
understand printer operation.
See “Status light” on page 11 for details.

DataCard SP55 Plus Specifications

General

Print Resolution	300 dpi
Card Capacity	100 card input hopper
Card Size	CR-80 (85.6 mm x 54 mm)
Interface	USB
Print Capability	Single-sided
Card Thickness	40 mil
Operating System Support	Windows 7
