DS2 Instruction Manual
24
Remote configuration from host user interface: synoptic table showing the output variation with
respect to the serial output configuration
Function
Mode
Outputs
Analog
Switching
Serial
Serial
Communication
Enable
SW
Enable
-
-
Comm. Enable
Disable
-
-
Comm. Disable
HW
pin5 RX connector
on 24Vdc
-
-
Comm. Enable
pin5 RX connector
floating
-
-
Comm. Disable
Serial Transmission
Type
ASCII
-
-
Type ASCII
Binary
-
-
Type Binary
Baud Rate
9600
-
-
-
19200
-
-
-
38400
-
-
-
57600
-
-
-
Data Sending Type
Cyclical
-
-
Send every
cycle
Output changes state
-
-
Send when
PNP/NPN
output changes
state
Analogue output changes
state
-
-
Send when
Analogue
output changes
state
On request
-
-
Send by host
request
Short Protocol
Binary only
-
-
Send with
short protocol
End of Serial
Packet
Trasmission
Not selected
-
-
-
Code
the serial
transmission is
finished by a fixed
sequence of 4-ASCII
characters “@EOP”
Delay
the serial
transmission is
delayed by a
equivalent time of 40
characters
transmissions at the
Baud Rate selected
 Short Protocol enables the transmission of one single char in binary code related to one single
measure. This protocol is available in remote configuration mode only, binary transmission.
 Detection analysis and output mode: allows to set the object detection mode (normal or Teach-in),
the normally open or normally closed switching output and any delay after detection. In the latter a
delay time ranging from 0 to 200 milliseconds can be selected.
 End of serial packet transmission: - selecting “Code”, the serial transmission is finished by a
fixed sequence of 4-ASCII characters “@EOP”.
- selecting “Delay”, the serial transmission is delayed by a
equivalent time of 40 characters transmissions at the
Baud Rate selected.
