Remote configuration from host user interface: synoptic table showing the output variation with
respect to the detection analysis mode configuration
Function
Mode
Outputs
Analogue
Switching
Serial
Complete
Beam
Status
Array
V=V
RES
*N
BEAM
[dark]
ASCII
Binary
Top
Beam
Dark (default)
V=V
RES
*N
BEAM
[Top;
reference]
Top Beam
ASCII
Binary
Light
V=V
RES
*N
BEAM
[Top light;
reference]
Top Beam
(light)
ASCII
Binary
Bottom
Beam
Dark (default)
V=V
RES
*N
BEAM
[Bottom;
reference]
Bottom
Beam
ASCII
Binary
Light
V=V
RES
*N
BEAM
[Bottom
light; reference]
Bottom
Beam (light)
ASCII
Binary
Middle
Beam
Dark (default)
V=V
RES
*N
BEAM
[0.5*(Top-
Bottom); reference]
Middle
Beam
ASCII
Binary
Light
V=V
RES
*N
BEAM
[0.5*(Top
light-Bottom light);
reference]
Middle
Beam (light)
ASCII
Binary
Total Beam
Dark (default)
V=V
RES
*N
BEAM
[dark]
Total Beam
ASCII
Binary
Light
V=V
RES
*N
BEAM
[dark]
Total Beam
(light)
ASCII
Binary
Total
Contiguous
Beam
Dark (default)
V=V
RES
*N
BEAM
[dark]
Total
Contiguous
Beam
ASCII
Binary
Light
V=V
RES
*N
BEAM
[dark]
Total
Contiguous
Beam (light)
ASCII
Binary
Total Beam
Light Dark
(default)
V=V
RES
*N
BEAM
[dark]
N.
Transitions
LightDark
ASCII
Binary
Dark Light
V=V
RES
*N
BEAM
[dark]
N.
Transitions
DarkLight
ASCII
Binary
Some sections exclude each other (one or the other), i.e. if the Beam Status
Array has been chosen as measurement 1, all the items of measurement 2
are deactivated. Another example: if Top Beam Dark has been chosen as
the first measurement, the operator can choose any other measurement
excluding the same type as the first and Beams Status Array. The items not
admitted become grey.
The settings will be memorised in the DS2 non-volatile memory pressing
the Update button.
The graphic will be restored with the last shape stored in the DS2 memory
by selecting the Download button.
Press End to quit configuration session. The system will request the exit confirmation.
