Datalogic Gryphon I GM440 Series Quick Reference Guide

Setting Up the Reader
6 Gryphon™ I GD44XX
Setting Up the Reader
Follow the steps below to connect and get your reader up and
communicating with its host.
1. Connect the Cable to the reader and the Host.
2. Configure the Interface (see page 8).
3. Configure the Reader starting on page 20 (optional,
depends on settings needed)
Connect/Disconnect Cable to Reader
Figure 1. Connecting to the Reader
Host Connection:
The Gryphon plugs directly into the host de-
vice as shown in
Figure 2. The power can also be supplied
through an external power supply via the Interface Cable sup-
plied with a power jack.
Figure 2. Connecting to the Host
U
S
B
