4.4 DATA FORMAT
4.4.1 Header/Terminator Selection
The header/terminator selection is not effected by the reading of the restore default
code. In fact, header and terminator default values
depend on the interface selection:
RS232 and USB-COM: no header, terminator CR-LF
WEDGE and USB-KBD: no header, terminator ENTER
WEDGE ALT-MODE and USB-KBD-ALT-MODE: no header, terminator CR
These default values are always
restored through the reading of the relative interface
selection code, see chapter 2.
For the WE
DGE interface, the following extended keyboard values can also be
configured:
EXTENDED KEYBOARD TO HEX CONVERSION TABLE
IBM AT
IBM 3153
APPLE ADB
IBM XT IBM 31xx, 32xx,
34xx, 37xx
Wyse
Digital
HEX KEY KEY KEY KEY
83 ENTER ENTER FIELD EXIT RETURN
84 TAB TAB TAB TAB
85 F1 F1 F1 F1
86 F2 F2 F2 F2
87 F3 F3 F3 F3
88 F4 F4 F4 F4
89 F5 F5 F5 F5
8A F6 F6 F6 F6
8B F7 F7 F7 F7
8C F8 F8 F8 F8
8D F9 F9 F9 F9
8E F10 F10 F10 F10
8F F11 ESC F11 F11
90 F12 BACKSPACE F12 F12
91 HOME HOME ENTER F13
92 END END RESET F14
93 PG UP PG UP INSERT F15
94 PG DOWN PG DOWN DELETE F16
95
↑ ↑
FIELD - UP
96
↓ ↓
FIELD + DOWN
97
← ←
ENTER (Paddle) LEFT
98
→ →
PRINT RIGHT
99 ESC ESC ESC
9A CTRL (Right) CTRL (Right) CTRL (Right)
9B Euro Space Space Space
For all readers using Wedge interface, all values from 9C to FE send the Space character.
