4.10 DEFAULT PARAMETERS FOR POS SYSTEMS

The default values for the RS232 and Data Format parameters for POS systems are

listed in the following table:

NIXDORF Mode A FUJITSU ICL Mode

RS232 Group

Baud Rate 9600 9600 9600

Parity Odd None Even

Data Bits 8 8 8

Stop Bits 1 1 1

Handshaking Hardware (RTS/CTS) None RTS always on

ACK/NACK Protocol Disabled Disabled Disabled

FIFO Disabled Enabled Enabled

Inter-Character Delay Disabled Disabled Disabled

RX Timeout 9.9 sec 2 sec 9.9 sec

Serial Trigger Lock

Disabled Disabled Disabled

Data Format Group

Code Identifier Custom Custom Custom

Header No Header No Header No Header

Terminator CR CR CR

Field Adjustment Disabled Disabled Disabled

Code Length TX Not Transmitted Not Transmitted Not Transmitted

Character Replacement Disabled Disabled Disabled

The table below lists all the Code Identifiers available for POS systems:

CODE NIXDORF Mode A FUJITSU ICL Mode

UPC-A A0 A A

UPC-E C0 E E

EAN-8 B FF FF

EAN-13 A F F

Code 39 M None C [code length]

Codabar N None N [code length]

Code 128 K None L [code length]

Interleaved 2 of 5 I None I [code length]

Code 93 L None None

Industrial 2 of 5 H None H [code length]

UCC/EAN 128 P None L [code length]

MSI/Plessey O None None

Code 11 None None None
