Datalogic IO-Link TL46 - Event Log; Event Codes and Descriptions; Device Variant Collection; Product Name and ID Mapping

Events
Event code (dec) Event name Event mode Event type Device status Remarks
0x4220 (16928) Temperature underrun Appears / Disappears Warning Out of specication
0x4210 (16912) Temperature overrun Appears / Disappears Warning Out of specication
0x5100 (20736) General power supply fault Appears / Disappears Error Failure
0x8CAA (36010) Short circuit - Check installation Appears / Disappears Error Failure
0x8CA0 (36000) Vibration overrun Appears / Disappears Warning Out of specication
0x8CA1 (36001) Shock detected One Shot Warning Out of specication
0x8CA2 (36002) Tilt angle exceeded Appears / Disappears Warning Out of specication
0x8CA3 (36003) Quality of signal underrun Appears / Disappears Warning Out of specication
PROCESS DATA
EXTENDED PARAMETERS
Switch Counter
Index
(dec)
Parameter
Object Name
Length
Subindex
(o󰀨set)
Value/Range Description Data Type Access* Remark
0x00B5 (181)
Switch Counter
Threshold
Reached
1 octet
0: false
1: true
State of Switch Counter Threshold Reached Boolean RO
0x00B6 (182)
Switch counter
settings
1 octet
1 octet
2 octets
1(24)
2(16)
3(0)
0: OFF (default)
1: Counter (STATIC)
2: Counter (AUTO)
0: Output Rising Edge
1: Output Falling Edge
0-32767
Mode
Trigger counter
Threshold counter
UIntergerT
Boolean
UIntegerT
RW
RW
RW
Saved in non-volatile memory.
Stop or reset the running counter
before changing conguration, then
re-enable the counter with Set counter
commands.
*Rising and falling egdes are referred
to DO pin.
0x00B7 (183)
Switch counter
values
1 octet
2 octets
1(16)
2(0)
0: counting UP
1: counting DOWN
2: counting INACTIVE (default)
-32,768..32,767
Counting direction
Switch counter value
UIntegerT
IntegerT
RO
RO
Index
(dec)
Parameter
Object Name
Length
Value
(dec)
Description Access
0x0002 (2) Reset counter 1 octet 0xA0(160) Reset counter value and the switch counter threshold exceeded (Static Mode only) WO
0x0002 (2) Enable counter UP 1 octet 0xA1(161) Enable counter and start count UP WO
0x0002 (2)
Enable counter
DOWN
1 octet 0xA2(162) Enable counter and start count DOWN WO
0x0002 (2)
Stop/Resume
counter
1 octet 0xA3(163) Freeze the counting function (all commutations are neglected: counting INACTIVE) or resume the counting function WO
DEVICE VARIANT COLLECTION
Product name Product ID
TL-46-WH-815-PZ 90004
TL-46-W-815-PZ 90005
Bit o󰀨set
Process Data Input
Byte 0
7 6 5 4 3 2 1 0
Analog signal (in Mark mode) LSB
Emission colors
Quality of
signal alarm
SSC1 (C/Q pin)
Byte 1
7 6 5 4 3 2 1 0
Analog signal (in Mark mode) MSB
