Datalogic IO-Link TL46 User Manual

TL46
parameters
PHYSICAL LAYER
Description
IO-Link Revision 1.1
SIO Modus YES
Min Cycle Time 2.3 ms
Transmission Rate 38.4 kbit/s (COM2)
Process Data Length
PDInput: 16 Bit
PDOutput: Not used
M-Sequence Capability
PREOPERATE: TYPE_0
OPERATE: TYPE_2_1
ISDU: supported
FEATURES
Description
Data Storage YES
Supported Access Locks Data Storage
Prole Characteristic
Device Prole: Smart Sensor
Function Class: Device Identication
Function Class: Switching Signal Channel
Function Class: Device Diagnosis
Function Class: Teach Channel
Function Class: Teach-in Single Value
SERVICE DATA
The following ISDUs will not be saved via Data Storage: Device Access Lock (index 0xC), Emitter Status (index 0x51), Device Temperature Threshold (index 0x53),
Quality of Signal Threshold (index 0x61) TI select (index 0x3A), Load Job (index 0x66), Select Job Number (index 0x67), Vibration Threshold (index 0x4C), Tilt
Threshold (index 0x4F), Shock Threshold (index 0x55), Timestamp Trigger (index 0xB8), Timestamp Sync Value (index 0xBB).
System Parameters
Index (dec)
Parameter
Object Name
Length Value/Range Description Data Type Access*
0x000C (12)
Device Access
Locks
2 octets Bit 1: Data Storage (0 = unlocked, 1 = locked)
Standardized Device locking functions:
Bit 1: Data Storage
Bit 2: Local parameterization (Not used)
Bit 3: Local user interface (Not used)
Bit 4-15: Reserved
Bit 0: not used
RecordT R/W
0x000D (13)
Prole
Characteristics
2 octets
2 octets
2 octets
2 octets
2 octets
2 octets
0x0001
0x8000
0x8001
0x8003
0x8004
0x8007
Smart Sensor Prole
Device Identication
Switching Signal Channel (SSC)
Device Diagnosis
Teach Channel
Teach-in single value
ArrayT of
UIntegerT16
RO
0x000E (14)
PDInput
Descriptor
3 octets
3 octets
3 octets
3 octets
0x01.0x01.0x00
0x01.0x01.0x01
0x01.0x02.0x02
0x01.0x0C.0x04
SSC1 (OUT0)
Quality of signal
Emission color
Analog signal
ArrayT of
OctetStringT3
RO
*RO = read only, WO = write only, R/W = read/write
Identication Parameters
Index
(dec)
Parameter Object
Name
Length
Subindex
(o󰀨set)
Value/Range Description Data Type Access* Remark
0x0010 (16) Vendor Name 9 octets DATALOGIC Informative StringT RO
0x0011 (17) Vendor Text 19 octets Empower your vision StringT RO
0x0012 (18) Product Name 14 octets See “Device variant collection” Detailed product name StringT RO
0x0013 (19) Product ID 5 octets See “Device variant collection” Product identication StringT RO
0x0014 (20) Product Text 15 octets Contrast Sensor Product text StringT RO
0x0015 (21) Serial Number 9 octets Unique serial number StringT RO
0x0016 (22) Hardware Revision 5 octets 1.0.0 StringT RO
0x0017 (23) Firmware Revision 5 octets 1.0.6 StringT RO
0x0018 (24) Application Specic Tag 32 octets *** (default)
Tag application dened
by user
StringT R/W
Saved in non-volatile
memory
0x0019 (25) Function Tag 32 octets *** (default)
Additional tag for device
function identication
StringT R/W
Saved in non-volatile
memory
0x001A (26) Location Tag 32 octets *** (default)
Additional tag for device
function identication
StringT R/W
Saved in non-volatile
memory
