Datalogic Magellan 1100i OEM

Integration Manual 5
Appendix A
Technical Specifications
Optical and Read Performance Parameters
Parameter Specification
Scan Volume
1147 cm
3
/ 70 in
3
Scan Pattern
136 scan lines
Scan Rate
1760 Digital Scan Lines/second
Minimum Resolution
5 mil
Depth of Field 
(100% UPC Labels)
Code Size Depth of Field
5 mil 25.4 - 57.2mm / 1.0 - 2.25”
7.5 mil 12.7 - 69.9mm / 0.5 - 2.75”
10 mil 12.7 - 139.7mm / 0.5 - 5.5”
13 mil 12.7 - 165.1mm / 0.5 - 6.5”
20 mil 12.7 - 184.2mm / 0.5 - 7.25”
Minimum Print Contrast
Ratio
25%
Skew (Yaw)
± 75 
Pitch
± 65 
Roll
Between 0 and 360 
Electrical Parameters
Parameter Specification
Operating Voltage Input voltage 4.5 to 14 VDC
Input Current

Operating (idle) 
Operating (label read) 
Surge Current (<30 ms)
<350mA
<450 mA
<600 mA
