Volume/Tone Push Button
The Volume/Tone Push Button also performs multiple functions depending upon
the duration of time it is pressed:
NOTE
Volume changes made using the Volume/T
one Push Button are lost
when the scanner is powered-down and are reset to the configured set-
ting. If you wish to permanently c
hange the volume, use the special
programming labels in the Product Reference Guide.
Table 1. Volume/Tone Push Button Functions
PRESS
DURATION
FUNCTION COMMENT
Momentary (when
scanner is asleep)
Wakes scanner from Sleep
Mode
Alternatively, the scanner can be awakened by:
- Moving an object through the scan zone.
- Scanning with an attached auxiliary scanner.
Momentary (when
scanner is a
wake)
Increments volume
Press the push button momentarily to increase speaker
v
olume. When the loudest volume is reached, a
repeated press of the push button cycles volume back
to the lowest setting, then volume increases on subse-
quent press(es). Four volume levels are available.
Hold, then release
when the beeper
sounds
Increments tone
Press the push button for approximately 2 seconds,
then release
. Each time this is done, the beeper will
sound at one of three tones. Stop when the desired
tone (high, medium or low) is sounded.
4 Seconds
Scanner Diagnostics Mode
a
a. By standard default, this function is normally disab
led to prevent accidental activation by users.
This mode allows system support personnel to trouble-
shoot problems with the scanner and is used to deter-
mine if it can read bar codes. Press the button for eight
seconds or cycle po
wer to exit Scanner Diagnostics
Mode and reset the scanner.
8 Seconds
Resets Scanner
b
b. Users should not perform scanner resets except under the direction
of trained systems support person-
nel.
Only system support personnel should perform a reset.
