Datalogic MAGELLAN 8300 Quick Reference Guide

8 Magellan™ 8300/8400
Scale Zero Push Button
The Scale Zero Push Button is used for two functions as described
in
Table 3. This button has no function on “scanner-only” models.
Table 3. Scale Zero Push Button Functions
PRESS
DURATION
FUNCTION COMMENT
Momentary Zero Scale
When programmed to do so, the yellow Scale LED should be
lit when no weight is on the scale, indicating scale at zero. If
it is not, press the switch to zero the scale. The unit will
sound a “click” upon pressing the button.
Momentary
(when the
scale’s pri-
mary indica-
tion shows an
under zero
condition)
Scale power
cycle
When programmed to do so, and when certain conditions
are met, pressing this button will initiate a scale power cycle.
When the scale zero button is pushed and the weight on the
scale is close to zero, the scale will zero normally like the
zero scale function above. Otherwise, the scale will go
through a power cycle. If the scale is able to find zero after
the power cycle, the scale will perform normally. Otherwise,
the scale’s primary indication will display a non-weight indi-
cation.
4 Seconds
Scale Diag-
nostics
Mode
a
This mode allows system support personnel to troubleshoot
problems with the scale. Cycle power to exit Scale Diagnos-
tics Mode.
a. Diagnostics Mode is meant for use by trained systems support personnel. Users should not need to initi-
ate this function under normal circumstances.

Datalogic MAGELLAN 8300 Specifications

General

Read rate (max)	3900 reads/s
Decoding standards	1D, GS1 DataBar
Standard interfaces	Keyboard Wedge, RS-232
USB 2.0 ports quantity	1
Input voltage	100 - 250 V
Product color	Metallic
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	102 mm
Width	292 mm
Height	130 mm
