MATRIX N FAMILY PARAMETERS LIST
23
4
4 MATRIX N FAMILY PARAMETERS LIST
The following tables present a complete list of parameters that can be modified using Host
Mode Programming.
The parameter strings shown here are the default ones.
The strings can be modified (personalized) through DL.CODE so it is advised to print them
out from DL.CODE for your specific configuration.
These strings are also dynamic. They depend on the order in which the configuration is
made. For example, each group of 2D or 1D Code parameters is associated with STRINGx
where “x” is a dynamically assigned number depending on the chronological order in which it
was configured. For this reason you must know the relative strings assigned by DL.CODE.
See par. 1.1 for details.
4.1 IMAGE SETUP
PARAMETER
TYPE
STRING
DATA
Image Polarity Inversion
2
IMAGE_POLARITYx
false = Disabled
true = Enabled
Exposure Time (s)
0
EXPOSURE_TIMEx
M450N all models
Disabled
33 to 64000
Very High-Power Strobed
33 to 500
High-Power Strobed
33 to 2500
Continuous High-Power
33 to 400
M410N all models
Disabled
10 to 64000
Always On
1000 to 64000
Very High-Power Strobed
10 to 500
High-Power Strobed
100 to 5000
Medium-Power Strobed
1000 to 64000
Continuous High-Power
10 to 300
M300N all models
Disabled
10 to 50000
Always On
1000 to 50000
Very High-Power Strobed
1 to 500
High-Power Strobed
100 to 3300
M210N-2xx-xxx
Disabled
10 to 26000
Always On
10 to 26000
Very High-Power Strobed
10 to 600
High-Power Strobed
100 to 5000
Medium-Power Strobed
1000 to 26000
M120-2xx-xxx
Disabled
10 to 15000
Very High-Power Strobed
10 to 1000
