MATRIX N FAMILY PARAMETERS LIST
27
4
PARAMETER
TYPE
STRING
DATA
Min Pixel per Module
0
2D_MIN_DOT_DIAMETERx
Range: 0 to 48
Max Pixel per Module
0
2D_MAX_DOT_DIAMETERx
Range: 0 to 48
Fixed Code Position
2
2D_CONSTANT_POSITIONx
false = Disabled
true = Enabled
PARAMETER
TYPE
STRING
DATA
2D CODE FILTER
Wildcard
3
2D_WILDCARD_CHARx
Length: 1 character
Placeholder
3
2D_PLACEHOLDERx
Length: 1 character
Min. Number of
Characters
0
2D_MIN_CHARx
Range 1 to 3116
Max. Number of
Characters
0
2D_MAX_CHARx
Range 1 to 3116
Code Quality
Standard
1
1
2D_CODE_QUALITY_STx
0 = Overall
1 = Decode
2 = Contrast
3 = Modulation
4 = Decodability
5 = Minimum Edge Contrast
6 = Axial Non Uniformity
7 = Unused Error Correction
9 = Minimum Reflectance
10 = Defects
11 = Fixed Pattern Damage
12 = Grid Non Uniformity
Code Quality Index
1
2D_CODE_QUALITY_INDEXx
0 = Any
1 = Grade A
2 = Grade B
3 = Grade C
4 = Grade D
1
Values depend on Code Type and Code Quality Standard. Not all parameters are valid for a given code.
