Exit and Save Configuration
Code 2
code ID
Read the code type from the Code Identifier Table B beginning in Appendix .
code length
Read a number in the range 01-99 from the Hex/Numeric Table.
Concatenation Result Code ID
use code 1 ID
use code 2 ID
Since you can concatenate codes from different families, you must select the Code ID character
of the resulting code. The Code ID character will be sent in the output message only if it is
enabled according to the Code Identifier selection (Datalogic, AIM, or Custom).
Concatenation Timeout
timeout
Read two numbers in the range 00 to 99
00= no timeout
01-99 = timeout from 1 to 99 seconds
Define the timeout, which determines the valid waiting period between the two codes, in order to
accept concatenation. If the timeout expires, the resulting action will be based on the following
selection. (HHDII)
