Datalogic PowerScan D8300 User Manual

Enter Configuration
Exit and Save Configuration
Ì$+;Î
16-KEY DK MODEL PARAMETERS
Ì$-?Î
142
define function key
 Read the above code to associate a Function Key or the Shift key (if defined as F5) .
 Specify which Function Key you want to associate (F1 – F4 or Shift
↑ F5) by scanning a
barcode (1-5) from the hex numeric table in the back of this manual.
 Select the label command you want to associate from the table on page 141. Scan a
barcode from the hex numeric table corresponding to the command ID (0-A)
Example : To define Function Key 1= Clear command
Define Function Key Func Key # CMD ID
Read +
1
+
7
STRING TABLE
The Powerscan 16-key model allows you to define a String Table, a database with room for five
entries, from String1 to String5, which can be recalled using a Function Key. This is done with
Function Key Programming, described on page 141.
The string can be a single ‘char’. Default = empty strings.
define string
 Read the above code.
 Select the string number you want to add by scanning a barcode (1 – 5) from the hex
numeric table in the back of this manual.
 Select the desired string length by scanning a barcode (0 – A) from the hex numeric table.
 Define the label string by scanning characters or numerals from the hex numeric table.
Example : To define String 1 = DATALOGIC
Define string String # Length Hex codes String text
Read +
2
+
9
+
44+41+54+41+4C
+4F+47+49+43
=
DATALOGIC


