POWERSCAN® D8530
118
PowerScan® D8530™ HD
Optical Features
Focus distance 65 mm
Field of view 27° (H) x 22° (V)
Horizontal field of view at
distance (d) in mm
0.50d + 13
Vertical field of view at distance
(d) in mm
0.40d + 10
Max Resolution
Linear codes -
mm (mils)
PDF 417 – mm
(mils)
Datamatrix – mm
(mils)
0.05 (2 mils) 0.08 (3 mils) 0.10 (4 mils)
Depth of field*
1D (linear): X-dimension
mm (mils)
DOF
cm (in)
Code39 0.08 (3) 4.5 to 8.0 (1.77 to 3.15)
0.13 (5) 3.5 to 9.5 (1.38 to 3.74)
0.51 (20) 6.0 to 18.5 (2.36 to 7.28)
EAN13 0.33 (13) 5.0 to 14 (1.97 to 5.51)
2D: X-dimension
mm (mils)
DOF
cm (in)
PDF417 0.08 (3) 5.0 to 8.5 (1.97 to 3.35)
0.13 (5) 4.5 to 9.5 (1.77 to 3.74)
0.25 (10) 3.0 to 13.0 (1.18 to 5.12)
QR 0.10 (4) 5.5 to 7.5 (2.17 to 2.95)
0.19 (7.5) 5.0 to 8.0 (1.97 to 3.15)
0.25 (10) 4.5 to 9.5 (1.77 to 3.74)
DATAMATRIX 0.10 (4) 5.5 to 7.5 (2.17 to 2.95)
0.19 (7.5) 5.0 to 8.0 (1.97 to 3.15)
0.25 (10) 4.5 to 9.5 (1.77 to 3.74)
Skew ±40°
Pitch ±35°
Rotation 360°
Print Contrast (Min.) 23%
• Reading distances are measured from the nose of the reader.
NOTE: Typical performance at 20ºC / 68ºF on high quality barcodes.
