Figure 1-1. Battery Pack Installation & Removal
Verifying Reader Operation Before Linking
Once a charged Battery Pack has been installed in the reader, scan a good sample barcode of the
symbology
1
type your reader is programmed to read. If unsure how to do this, see the section on
How to Scan in this manual. Tip: The part number barcode on the back cover of this manual is
a Code 39 symbology sample.
The system may signal with one or a combination of indicators depending upon the "connection"
status of the reader (see LED and Beeper Indications for details). If your reader fails to read a sample
barcode of a symbology it is programmed to read, turn to the section titled,
Troubleshooting.
1. To enable more barcode symbology types, reference the Product Reference Guide (PRG).
Scanner
Alignment Pins
Release Latch
Release Latch
Battery
Pack
To Next Page
