Datalogic QuickScan Lite QW2100 Quick Reference Guide

28 QuickScan
TM
Lite QW2100
USB Interface
The reader attaches directly to a USB host, or a powered
USB hub, and is powered by it. No additional power sup-
ply is required. When using a USB interface, the reader
auto-detects the USB and defaults to the USB Keyboard
interface.
Select USB-COM-STD
1
(simulates RS-232 standard interface)
Select USB Keyboard (with standard key encoding)
Select USB Alternate Keyboard (with alternate key encoding)
Select USB OEM
1. Download the correct USB Com driver from www.datalogic.com.

Datalogic QuickScan Lite QW2100 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Read rate (max)	400 reads/s
Yaw reading angle	-70 - 70 °
Tilt reading angle	-45 - 45 °
Pitch reading angle	-65 - 65 °
Linear (1D) barcodes supported	EAN 5, EAN-13, EAN-8, GS1-128 (UCC/EAN-128)
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	340 mA
Power source type	DC
Product color	Black
Housing material	-
International Protection (IP) code	IP42
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	65 mm
Width	170 mm
Height	70 mm
Weight	119 g
