Setting Up the Reader
QUICK REFERENCE GUIDE
5
Reader, Cradle and LEDs Description
LEDs on the gun provide information about the battery
charging status as well as data transmission.
Figure 3 - QuickScan Reader and Cradle Features
Description
1. Scan Window 3. Battery & Recharge LED
2. Trigger 4. USB Port
1. Communication Port 3. Battery Charging Status
LED
2. Service Button 4. Power LED
2
3
4
1
1
2
3
4
