SYSTEM AND NETWORK LAYOUTS
Stand Alone Layouts
Figure 5 - Single Reader Layout
Figure 6 - Multiple Stand Alone Layout
Many stand alone connections can operate in the same
physical area without interference, provided all readers
and cradles in the system have different addresses.
HOST
QBT/QM2500
CRADLE
