Enter/Exit Programming Mode Code 128

124 QuickScan™ I QD24XX/QBT24XX/QM24XX

Code 128 Set Length 2

This feature specifies one of the bar code lengths for Code 128 Length Control on page 122.

Length 2 is the maximum label length if in Variable Length on page 243 Mode, or the second

fixed length if in Fixed Length on page 243 Mode. Length includes the bar code’s data charac-

ters only.

The length can be set from 1 to 80 characters. A setting of 0 specifies to ignore this length

(onl

y one fixed length).

Table 6 provides examples for setting Length 2. See page 243 for detailed instructions on set-

ting this feature.

Table 6. Code 128 Length 2 Setting Examples

STEP ACTION EXAMPLES

1 Desired Setting

00 (Ignore This

Length)

07 Characters 15 Characters 80 Characters

2 Scan ENTER/EXIT PROGRAMMING MODE

3 Scan SELECT CODE 128 LENGTH 2 SETTING

Scan Two Characters From

Appendix D, Keypad

‘0’ and ‘0’ ‘0’ and ‘7’ ‘1’ and ‘5’ ‘8’ and 0’

5 Scan ENTER/EXIT PROGRAMMING MODE

$CC8L2

Select Code 128 Length 2 Setting

Make a mistake? Scan the CANCEL bar code to abort and

not save the entry string. You can then start again at the

beginning.

CANCEL

DEFAULT

80 = Length 2 is 80 Characters
