Item Description
Performance Characteristics
Light Source LEDs
Roll (Tilt) Tolerance Up to ± 360°
Pitch Tolerance ± 65°
Skew (Yaw) Tolerance ± 60°
Field of View 40° Hx26° V
Print Contrast Minimum 25% minimum reflectance
Depth of Field (Typical)
a
a. 13 mils DOF based on EAN. All other 1D codes are Code 39. All labels grade A, typical environmental
light, 20°C, label inclination 10°
Symbology
Code 39
5mil: 0.2" - 5.9" (0.5 - 15cm)
10mil: 0" - 8.7" (0 - 22cm)
20mil: up to 16" (40cm)
EAN
7.5mil: 0" - 5.9" (0 - 15cm)
13mil: 0.2" - 13.8" (0.5 - 35cm)
PDF 417
6.6mil: 0.39" - 5.1" (1.0 - 130cm)
10mil: 0" - 8.3" (0 - 21cm)
15mil: 0.2" - 9.5" (0.5 - 24cm)
Data Matrix
10mil: 0.39" - 5.1" (1.0 - 13 cm)
15mil: 0" - 7.1" (0 - 18cm)
QR Code
10mil: 0.2" - 5.1" (0.5 - 13cm)
15mil: 0" - 7.1" (0 - 18cm)
Minimum Element Width
Standard Range:
1D Minimum Resolution = 4 mil
PDF-417 Minimum Resolution = 5 mil
Data Matrix Minimum Resolution = 7.5 mil
Technical Specifications
266 QuickScan™ I QD24XX/QBT24XX/QM24XX
