SC6000 QUICK GUIDE
15
Menu Mode
For security purposes, the menu mode is entered by pressing the Enter and Menu keys at the same time. To
navigate in the menus the keypad keys are used as follows:
Press Enter to select an item or enter a branch level.
Press Clear to exit an item without saving or return to the previous branch level.
Press the Up or Down arrow keys to scroll through a branch list.
It is possible to access the System menu, Setup parameters menu or the PackTrack menu:
Menu Branch Branch Note
System
Info Shows the System Info Window
Reset Reset the system (asks for confirmation)
Restore DARP Restore procedure
Complete Restore system configuration
All Slaves Restore only all slaves configuration
Controller Restore only SC6000 configuration
Slave … Restore single specific slave configuration
Backup DARP Backup procedure
Complete Backup system configuration
All Slaves Backup only all slaves configuration
Controller Backup only SC6000 configuration
Slave … Backup single specific slave configuration
Last Codes
(if enabled)
Shows the last 10 codes read:
Up or Down to scroll through the list; one code per display
screen
The Backup and Restore procedures can also be performed in Genius™, (see the Reference Manual for details).
Menu Branch Branch Note
Setup
Time Set system time:
Up & Down to change values, Enter to change fields, at last
field Enter exits saving new values
Date Set system date:
Up & Down to change values, Enter to change fields, at last
field Enter exits saving new values
Ethernet Primary Ethernet interface
IP addr Set IP Address
GW addr Set Gateway Address
Net mask Set Netmask
MAC addr
(it is advised not to change this value)
DeviceNet addr DeviceNet node address
(only DeviceNet models)
Profibus addr Profibus node address
(only Profibus models)
Add. Ethernet supplementary Ethernet interface
(only Dual Ethernet models)
IP addr IP Address
GW addr Gateway Address
Net mask Netmask
MAC addr
(it is advised not to change this value)
The Address parameters may be set through Genius™, (see the Help On-Line or the Reference Manual for
details.
