TECHNICAL FEATURES
ELECTRICAL FEATURES
Supply Voltage 10 to 30 Vdc
Power Consumption 650 mA to 217 mA; 6.5 W typical
800 mA to 300 mA; 9 W Max. (including startup current)
Main (isolated) Auxiliary Modem
RS232, RS485 full-duplex RS232 RS232
Other
Lonworks 1.25 Mb/s
Communication Interfaces
Ethernet 100 Mb/s
Model–Dependent Communication
Interfaces
Ethernet (dual)
DeviceNet
Profibus
100 Mb/s
up to 500 Kb/s
up to 12 Mb/s
Inputs (optocoupled NPN or PNP) Encoder, PS, PS Aux, 3 polarity insensitive optocoupled inputs
Outputs (optocoupled) 6 optocoupled outputs, 3 relay control inputs
USER INTERFACE
LCD Display 4 lines by 20 characters LCD
Keypad 6 keys
LED Indicators Power ON
TX data
RX data
Ethernet
PS
PS Aux
TACH
Networks
Controller
Scanners
SOFTWARE FEATURES
Configuration Modes
Genius™ utility program
Parameter Storage
Non-volatile extractable FLASH card
ENVIRONMENTAL FEATURES
Operating Temperature 0° to +50 °C (+32° to +122 °F)
Storage Temperature -20° to +70 °C (-4° to +158 °F)
Humidity 90% non condensing
Vibration Resistance
EN 60068-2-6 14 mm @ 2 to 10 Hz; 1.5 mm @ 13 to 55 Hz;
2 g @ 70-200 Hz; 2 hours on each axis
Shock Resistance
EN 60068-2-27 30 g; 11 ms;
3 shocks on each axis
Protection Class
EN 60529 IP64*
PHYSICAL FEATURES
Mechanical Dimensions 320 x 250 x 90 mm (12.6 x 9.84 x 3.54 in)
Weight 3.3 kg. (7.26 lb)
* sealed connectors required, including the Harting RJ Industrial® Push Pull Ethernet connector.
