Congratulations on your purchase of the VisionSC-UHD2. This high performance capture card provides highest resolution video
oering both detail and colour accuracy when creating the most stunning visual displays. From command and control rooms to
reception areas, collaboration environments and digital signage applications, the VisionSC-UHD2 ensures the very best quality
and ultimate customer satisfaction.
Providing two HDMI 2.0 capture channels with HDCP 2.2 at 4K60p with full 4:4:4 chroma sampling, the VisionSC-UHD2
compliments our hugely successful VisionSC capture card family and oers unparalleled performance in frame grabber
technology.
Features
• Two independent HDMI 2.0 capture channels with HDCP 2.2 support.
• x8 PCIe Gen.3 interface providing 6GB/s total capture bandwidth.
• 2GB of frame buer memory.
• Full 10-bit signal processing.
• Includes the Vision Performance Feature set.
Vision Performance Features
LiveStream
• Low latency video and audio capture minimises the delay prior to post processing.
MultiStream
• Independently control and route up to 16 video clients per card. These can all be on the same input or split between inputs.
Powerful hardware scaler
• Adjust the incoming video size to your requirements in real time without incurring latency or using CPU resources.
Text and bitmap overlay
• Overlay text and images onto the capture buer.
Automatic video signal detection
• Accurate signal detection for all signal sources.
Colour Space Converter
• Format converter eliminates the need for user post processing.
Hardware Timestamping
• Provides precise knowledge of when a frame is captured.
Flexible and congurable EDID Management
• Allows programming of custom EDID parameters for capture cards using the Vision Congure dialogue.
Support for third party graphics cards
• Compatibility with AMD DirectGMA.
• Compatibility with Nvidia GPUDirect .
3
Introduction
