Software Features
The application displays the connected source in a window; it has the following features:
• Scales the data to t in the window.
• Ability to set up sources accurately (settings automatically saved).
• Save a single frame to a le in one of the following formats:
BMP, JPEG, GIF, TIFF, PNG.
• Print a single frame.
• Maintain the aspect ratio of the displayed captured data.
• Cropping.
• Display text over the data (on-screen display).
• Command line interface.
• Help le documenting all features.
8
Vision Application Overview
Vision capture cards are supplied with a powerful software application for conguring the format of the input sources and
displaying the data in various ways.
The Vision application is available when a Vision window is opened:
Start | Programs | Vision | Vision window
Vision Congure
Vision Congure is a comprehensive EDID management tool which enables the user to program custom EDID parameters for all
capture cards.
To open the Vision congure dialogue:
Start | Programs | Vision | Vision Congure
