PREPARING FOR THE INSTALLATION
PREPARING FOR THE INSTALLATION
Main Board Jumper Setting and Connector
Denition
Top Side
S-615W
SoC
SATA1
Battery
LED1
S2
VGA1
LAN1 USB1 USB2 COM1 COM2 COM3 Cash
Drawer1
DC2 DC1
TOP and Bottom Side Layout Content List
Top Side Connector Information
Item Connector Denition
LED1 Power LED
S2 Power Trigger
SATA1 7+15 SATA Port
