PREPARING FOR THE INSTALLATION
System Default Settings
The following is the information on default settings for Touch Terminal serial ports.
Voltage Output Denition
S-615W/ S-715W
Voltage Output
Connector Item Power Support
COM 1 for extension 5V / 12V Select by jumper
COM 2 for extension 5V / 12V Select by jumper
COM 3 for extension 5V / 12V Select by jumper
Cash Drawer 24V / 12V Select by jumper
DC Output 12V
USB 2.0 5VSB
USB 3.0 5VSB
COM Port Setting Denition
S-615W
Item COM1 COM2 COM3 COM4 COM5
I/O Address 3F8 2F8 3E8 2E8 2F0
IRQ Setting IRQ4 IRQ3 IRQ5 IRQ10 IRQ11
S-715W
Item COM1 COM2 COM3 COM4 COM5
I/O Address 3F8 2F8 3E8 2E8 2F0
IRQ Setting IRQ4 IRQ3 IRQ5 IRQ10 IRQ7
Cash Drawer Setting Denition
S-615W
COM Port I/O Address Baud Rate Open Command Respond Command
COM5 2F0 9600 01h 02h
S-715W
COM Port I/O Address Baud Rate Open Command Respond Command
COM5 2F0 9600 07h 02h
