Datavan S-615W - Bottom Side

22
PREPARING FOR THE INSTALLATION
PREPARING FOR THE INSTALLATION
Bottom Side
S-615W
JUSB3 COM4 LVDS1 CONVERTER1
SO DIMM1
JUSB1 JUSB2
Bottom Side Layout Content List
Bottom Side Connector Information
Item Connector Denition
JUSB1/JUSB2 USB 2.0
JUSB3 USB 2.0
LVDS1 LVDS Single/Dual Channel
CONVERTER1 LCD Backlight Converter
COM4 COM 4 Serial Ports
